FiberSabre 6kW Fiber Laser
The next level solution for your American-made Fiber Laser needs.
Starting at $101,995.00
Finance for as low as $1,781/month
Note: shown with optional equipment.
Description
LASER ACCURACY. AMERICAN BUILT.
The ShopSabre FiberSabre 6kW is a production-grade 6kW fiber laser cutting machine engineered for metal fabrication shops that need to bring cutting in-house and keep it running.
Available in versatile 4’x8′ and 5’x10′ configurations, it cuts through a wide range of metals, including steel, stainless steel, aluminum, copper, and brass, with speed and edge quality your parts and margins depend on. Designed with productivity and ease of use in mind, the FiberSabre features a material pull-out drawer for seamless loading and unloading, reducing downtime and ensuring a smoother workflow. Additionally, clean-out drawers make routine maintenance straightforward and efficient, keeping your workspace clean and your machine running at peak performance.
At the core of the FiberSabre’s performance is its AC Closed Loop Servo Technology, delivering precise, reliable movement control that minimizes errors and maximizes cutting quality. The entire setup is housed in a full safety enclosure, enhancing operator safety by containing laser emissions and debris, ensuring a safe working environment for your team. With the ShopSabre FiberSabre, you’re investing in industry-leading technology that combines top-tier performance with user-friendly features, elevating your capabilities and productivity.
Every FiberSabre is engineered, manufactured, and supported in the USA and backed by lifetime tech support and training. You’re not buying an import and hoping for service; you’re buying a machine that shows up ready to work and a team that answers the phone.
Read MoreRead Less
Proudly made and Based in the USA
Lifetime Tech Support
CNC Training For Life
Financing Available
Highlighted Features
- Dual-Driven Y-Axis (Long Axis)
- Powered 100% by high-torque industrial brushless AC digital closed-loop servo motors with encoder technology
- Direct Drive Planetary Gear Reduction on the XY-axis
- Advanced Direct Drive Ball Screw for the Z-axis
- Industrial welded, stress-relieved, and aerospace-milled structural steel tube gantry construction. Watch our steel vs aluminum video!
- Industrial structural steel tube welded, non-suspension-style frame with steel tube reinforcement for added stabilization and increased rigidity. No extruded aluminum, suspended table, or low-cost bolt-together designs.
- No assembly required
- High-performance 25mm linear profile guide rails and bearings with quad rollers on all axes
- ShopSabre exclusive low-maintenance inverted rack-and-pinion system to reduce maintenance and increase torque
- Collision-detection laser head with integrated advanced digital capacitance torch height control
- Industrial continuous flex robotic wiring with enclosed wire carriers for wiring protection and noise isolation
- Complete set of table slats with slat brackets installed at the factory
- Easy-to-learn software with point-and-click technology, including at-machine CAD/CAM capabilities
- Integrated laser cut charts with a pre-configured material library
- At-machine solid-state hard drive for easy job storage and dedicated high-speed multi-axis controller technology
- Includes tracing technology, as seen on PowerBlock TV Watch our search and restore video.
- Free SabreNation lifetime tech support via phone, email, and remote diagnostics Watch our support video.
- Free SabreNation lifetime training and SabreNation University access
- Included complete warranty
- Quick and effortless installation – machine ships fully assembled with no installation assistance required
- MADE IN THE U.S.A. — American manufactured and engineered using FEA software Watch our engineering video.
Read MoreRead Less
FiberSabre 6kW 408 |
FiberSabre 6kW 510 |
|
| Footprint | 147" x 154" x 75" | 171" x 178" x 75" |
| Cut Area | 49" x 97" | 61" x 121" |
| Z Clearance | 6.375" | 6.375" |
| Z Travel | 7.5" | 7.5" |
| Cutting Capacity | 15/16" - Laser Wattage Limited | 15/16" - Laser Wattage Limited |
| Positional Repeatability | +/-.002" | +/-.002" |
| Rapid Traverse | 3500IPM | 3500IPM |
| Laser Power | 6KW | 6KW |
| Well Equipped | $101,995.00 | $106,995.00 |
| Get a Quote | Get a Quote | |
Finance for as low as $1,781.00/month |
Finance for as low as $1,868.00/month |
Finance CalculatorWhat the FiberSabre 6kW Cuts
A 6kW fiber laser gives you the power to cut thick plates and the finesse to run thin sheets at high cutting speed. Here’s what the FiberSabre 6kW handles:
| Material | Thickness Range (Inch / Mm) | Optimal Production |
Extended Capability | Maximum Thickness | Typical Assist Gas | Best Performance |
|---|---|---|---|---|---|---|
|
MILD / CARBON STEEL
|
22 ga – 1″ (0.8 mm – 25 mm) |
22 ga – 5/8″ (0.8 mm – 16 mm) High speed, clean cuts, excellent productivity |
5/8″ – 7/8″ (16 mm – 22 mm) Good results with optimized settings |
7/8″ – 1″ (22 mm – 25 mm) Achievable with slower speeds, higher gas use, more tuning |
Oxygen (or Nitrogen for oxide-free cuts) |
Fast production with oxygen or clean nitrogen cutting |
|
STAINLESS STEEL
|
22 ga – 3/4″ (0.8 mm – 20 mm) |
22 ga – 1/2″ (0.8 mm – 12 mm) Burr-free, oxidation-free edge quality |
1/2″ – 11/16″ (12 mm – 18 mm) Good quality with tuned parameters |
11/16″ – 3/4″ (18 mm – 20 mm) Achievable with slower speeds, higher gas use, more tuning |
Nitrogen (or Air for certain alloys) |
High-quality, burr-free, oxidation-free finished parts |
|
ALUMINUM
|
0.040″ – 5/8″ (1 mm – 16 mm) |
0.040″ – 3/8″ (1 mm – 10 mm) High-speed cutting, excellent edge quality |
3/8″ – 1/2″ (10 mm – 12 mm) Good results with proper setup |
5/16″ – 3/8″ (8 mm – 10 mm) Achievable with slower speeds, higher gas use, more tuning |
Nitrogen (or Air for certain alloys) |
High-speed fabrication with excellent edge quality |
|
BRASS
|
0.040″ – 3/8″ (1 mm – 10 mm) |
0.040″ – 1/4″ (1 mm – 6 mm) Clean cuts, good edge quality, high accuracy |
1/4″ – 5/16″ (6 mm – 8 mm) Good results with tuned parameters |
5/16″ – 3/8″ (8 mm – 10 mm) Achievable with slower speeds and optimized settings |
Nitrogen |
Precision electrical and decorative components |
|
COPPER
|
0.040″ – 3/8″ (1 mm – 10 mm) |
0.040″ – 1/4″ (1 mm – 6 mm) Best results on thinner material |
1/4″ – 1/8″ (6 mm – 8 mm) Good results with proper setup |
5/16″ – 3/8″ (8 mm – 10 mm) Achievable with slower speeds, higher gas use, more tuning |
Oxygen or Nitrogen | Thin conductive parts with proper setup |
| OPTIMAL PRODUCTION |
| Where the machine really shines. Best combination of speed, edge quality, and productivity. |
| EXTENDED CAPABILITY |
| Excellent results with appropriate setup and parameter optimization. May require reduced speeds. |
| MAXIMUM THICKNESS |
| Achievable but may require reduced speeds, additional process tuning, and may not be suitable for every application. Secondary cleanup may be needed on the edge or burr. Not designed for production running. |
IMPORTANT NOTES:
- Performance at the upper end of each range requires: reduced cutting speeds, longer pierce times, higher assist gas consumption, optimized consumables & process settings.
- The machine can cut beyond the optimal production range, but results will vary.
- A compressor can be used at the proper pressure. However, there is a reduction in cut quality and speed a lot of times.
- Material type, alloy, surface condition, edge quality requirements, and part geometry can all affect achievable results.
- Thicknesses shown are for reference using standard material grades and ideal cutting conditions.
- ShopSabre recommends part testing for critical applications.
- Fume extraction is required. Some metals could produce toxic gas and precautions shall be needed.
Questions?
Are you not sure which CNC machine is right for you and your production? Schedule a free consultation with one of our in-house experts for personalized, one-on-one guidance.
FiberSabre 6kW Fiber Laser Features
Industrial Precision Frame
ShopSabre CNC frames are FEA-engineered and tested, constructed from plate steel construction which are welded for added rigidity and supported laterally along the floor to suspending no weight. Each FiberSabre Series frame features an industrial plate steel braced floor design, providing increased floor contact and superior vibration control.
FiberSabre 6kW Fiber Laser Features
AC Digital Servo Motors
ShopSabre FiberSabre machines come standard with AC-powered digital closed-loop servo motors featuring glass encoder technology. These motors provide higher speeds, greater accuracy, and reduced maintenance compared to traditional machines in this class, achieving impressive speeds of up to 3500 IPM as standard. The self-monitoring encoder technology ensures extreme performance, as closed-loop servos eliminate missed steps, loss of accuracy, and loss of torque. These servos offer enhanced acceleration and motor stability, which benefits thin materials, tighter tolerance cutting, and extended duty cycles.
FiberSabre 6kW Fiber Laser Features
Advanced Drive Technology
ShopSabre FiberSabre Series machines are driven by oversized rack-and-pinion systems on the XY axis, and re-circulating ball-screw technology on the z-axis. This technology reduces debris contamination and allows the rack-and-pinion system to self-align for decreased wear, increasing gear performance, extending gear life, and reducing maintenance.
FiberSabre 6kW Fiber Laser Features
Aero Space Milling Technology
ShopSabre CNC frame and gantry systems undergo some of the world’s most advanced processes to ensure precision, including the precision milling of contact surfaces for bearing and rail placement. A machine can only be as accurate as its foundation, so the frame on a ShopSabre is built to a higher tolerance than the competition.
FiberSabre 6kW Fiber Laser Features
Industrial Z Axis Technology
ShopSabre FiberSabre machines use twin rails on the Z-axis with four bearings and industrial ball screw drive technology. Every ShopSabre laser includes advanced digital capacitance torch height control with collision avoidance technology for quick and easy cutting.
FiberSabre 6kW Fiber Laser Features
Industrial Precision Frame
ShopSabre CNC frames are FEA-engineered and tested, constructed from plate steel construction which are welded for added rigidity and supported laterally along the floor to suspending no weight. Each FiberSabre Series frame features an industrial plate steel braced floor design, providing increased floor contact and superior vibration control.
FiberSabre 6kW Fiber Laser Features
AC Digital Servo Motors
ShopSabre FiberSabre machines come standard with AC-powered digital closed-loop servo motors featuring glass encoder technology. These motors provide higher speeds, greater accuracy, and reduced maintenance compared to traditional machines in this class, achieving impressive speeds of up to 3500 IPM as standard. The self-monitoring encoder technology ensures extreme performance, as closed-loop servos eliminate missed steps, loss of accuracy, and loss of torque. These servos offer enhanced acceleration and motor stability, which benefits thin materials, tighter tolerance cutting, and extended duty cycles.
FiberSabre 6kW Fiber Laser Features
Advanced Drive Technology
ShopSabre FiberSabre Series machines are driven by oversized rack-and-pinion systems on the XY axis, and re-circulating ball-screw technology on the z-axis. This technology reduces debris contamination and allows the rack-and-pinion system to self-align for decreased wear, increasing gear performance, extending gear life, and reducing maintenance.
FiberSabre 6kW Fiber Laser Features
Aero Space Milling Technology
ShopSabre CNC frame and gantry systems undergo some of the world’s most advanced processes to ensure precision, including the precision milling of contact surfaces for bearing and rail placement. A machine can only be as accurate as its foundation, so the frame on a ShopSabre is built to a higher tolerance than the competition.
FiberSabre 6kW Fiber Laser Features
Industrial Z Axis Technology
ShopSabre FiberSabre machines use twin rails on the Z-axis with four bearings and industrial ball screw drive technology. Every ShopSabre laser includes advanced digital capacitance torch height control with collision avoidance technology for quick and easy cutting.
FiberSabre 6kW Fiber Laser Features
Precision Linear Guide Technology
Industrial Precision Gantry
Industrial Machine Control Included
Enclosed Laser Wiring
Planetary Gear Driven
