Note: shown with optional equipment.
The World’s Fastest and Most Accurate CNC Control!
The ShopSabre IS-M Series is the First CNC Router in the world to be equipped with a Mitsubishi M8 Series Control. The ShopSabre IS-M Series gives you a true machine-grade tool with everything you could want in a CNC router + an Industrial Grade Mitsubishi Electronic Motion Control Platform. The Mitsubishi M8 Series control brings Speed and Performance not found on a CNC Router until NOW!
The IS-M series features a re-enforced heavy-duty one-piece welded structural steel tube frame construction with a massive over-sized structural steel tube gantry design. The frames and gantry assemblies are bed milled for matched tolerances and stressed relieved to ensure accuracy and precision from the ground up. This System provides you the Ultimate Stability and Performance while unlocking Speed and Accuracy not found in competitively priced systems.
The days of imported technology are in the past – you now can get a TRUE American Made Machine with a Name Brand Industrial Mitsubishi Electronic Motion Controller for a competitive price to the imported machines. The IS-M Series is equipped with the most advanced drive technology in the class – massive ball screws on X, dual Y, and Z axis with ShopSabre Exclusive “Whip Free” Technology. The Mitsubishi over-sized AC servo motors with Closed Loop feedback provide unmatched performance and dependability. The IS-M Technology improves cutting quality, cutting forces, and overall machine accuracy giving you Higher Speeds and Higher Cutting Accuracy than any machine in the class. Unlike our competition this machine is equipped with absolutely no rack and pinion drives, ShopSabre machines are built to outlast and outperform other machines. No matter how much you use your CNC router, you’ll get the precision you need every time from the ShopSabre IS-M Series. Perfect for all high production, high accuracy, or heavy cutting applications whether you are nested-based manufacturing or one-off fabrication, the state-of-the-art IS-M Series features three sizes (4’x8’, 5’x10’, and 6’x12’) built precisely for your needs.
Contact us today to learn more about the ShopSabre IS-M Series CNC routers.
Need Commercial Financing? No problem, with payments as low as $780/month
IS-M 408
Footprint:
99" x 121" x 95"
Cut Area:
50" x 98" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $64,800
|
$54,800
|
|
As low as
|
$1,105/month
|
|
Starting at with Rotary ATC: $75,545
|
$65,545
|
|
As low as
|
$1,322/month
|
IS-M 510
Footprint:
111" x 149" x 95"
Cut Area:
62" x 122" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $67,300
|
$57,300
|
|
As low as
|
$1,155/month
|
|
Starting at with Rotary ATC: $78,045
|
$68,045
|
|
As low as
|
$1,372/month
|
IS-M 612
Footprint:
124" x 173" x 95"
Cut Area:
74" x 146" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $72,000
|
$62,000
|
|
As low as
|
$1,250/month
|
|
Starting at with Rotary ATC: $82,745
|
$72,745
|
|
As low as
|
$1,467/month
|
- IS-M 408
- IS-M 510
- IS-M 612
IS-M 408
Footprint:
99" x 121" x 95"
Cut Area:
50" x 98" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $64,800
|
$54,800
|
|
As low as
|
$1,105/month
|
|
Starting at with Rotary ATC: $75,545
|
$65,545
|
|
As low as
|
$1,322/month
|
IS-M 510
Footprint:
111" x 149" x 95"
Cut Area:
62" x 122" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $67,300
|
$57,300
|
|
As low as
|
$1,155/month
|
|
Starting at with Rotary ATC: $78,045
|
$68,045
|
|
As low as
|
$1,372/month
|
IS-M 612
Footprint:
124" x 173" x 95"
Cut Area:
74" x 146" x 12"
Z Clearance:
12" standard
Drive Motors:
AC Servo Motors
Drive System:
Ball Screw X, Dual Y, and Z axis
Control System:
Mitsubishi M80 Control
Pricing Options:
|
Starting Price Without ATC: $72,000
|
$62,000
|
|
As low as
|
$1,250/month
|
|
Starting at with Rotary ATC: $82,745
|
$72,745
|
|
As low as
|
$1,467/month
|
IS-M Series CNC Router Features
1
2
3
4
5
6
7
8
9
10
11
12
1. Industrial Precision Frame
ShopSabre CNC Frames are
FEA Engineered and Tested
constructed from Massive 10x15 Steel Tubes which are Stacked and Welded for added rigidity giving you more floor
contact and better vibration control. Internally the large tubes are also cross braces and stiffened to increase the rigidity.
2. Mitsubishi Servo Motors
ShopSabre PRO Machines come standard with AC Digital Closed Loop Servo Motors for
Higher Speeds, Higher Accuracy, and Less Maintenance–Self Monitoring Glass Encoder Technology provides extreme performance
and the IS-M Controller allows for on the fly control from Controller to Motor with True CLOSED Loop to the Machine controller–Mitsubishi is Top Rated Servo Technology in the World!
3. Aero Space Milling Technology
ShopSabre CNC Frames are Run through some of the world’s most advanced processes to assure they are accurate including Precision Milling of contact surfaces for Bearing & Rail Placement along with Ball Screw Mounts. A machine can only be as accurate as it’s foundation so the Frame on a ShopSabre is built to a tolerance above the competition.
4. Ball Screw Technology
ShopSabre IS-M Machines come standard with 3 Axis Ball Screw Drives with Y Axis (Long Axis) providing Twin Screws to give you 7 times more rigidity than competing machines and
unprecedented performance. Ball Screw Technology used at ShopSabre is the latest in the Industry including which gives you less backlash than Rack and Pinion and thanks to our Whip Free Technology it increases the cutting accuracy and gives you superior edge finishes–Ball Screw Technology will outlast most comparable machines by as much as 3 to 4 times longer with very little maintenance required.
5. Mitsubishi M8 Series Controller
The M in IS-M comes from the Mitsubishi M8 Series Controller. The ShopSabre IS-M brings unbelievable performance to CNC Routing. The IS-M is the first CNC Router in the world to display a M8 Series controller which is the world's fastest CNC Control. The IS-M controller has the simplicity of our world known CNC interface but the robust speed and communication of a dedicated Mill Style Control. Providing Increased machining speeds,
accuracy, and performance the IS-M brings you technology that is indisputably better!
6. Vacuum Performance
The Vacuum Option on the ShopSabre IS-M Series gives you quick and easy zone control with integrated hard pipe connection for increased air flow and the reserve tank built into the frame to assure your vacuum stays consistent!
7. HiFlow Vacuum Technology
ShopSabre CNC HiFlow Vacuum Technology increases the surface flow by as much as 50% over the competition which in the end results in higher holding pressures and power and better performance. Each Vacuum table on the IS-M Series comes Milled from the factory by your machine cutting head reducing the needs for gaskets and bolts
to hold your spoil board down and our exclusive HiFlow Grid makes nested manufacturing a breeze.
8. Super Z Technology
ShopSabre IS-M Machines are
available with the Super Z Technology designed here at
ShopSabre CNC. This increases your Z Axis to 16” of Travel while maintaining incredible rigidity thanks in part to our FEA Engineered Stiffener Technology for Tool Plate Strength and our Z Axis Servo Motor Control System and Air Balancer Technology giving you some of the quickest Tool Changes and Drilling cycles in the class!
9. Precision Linear Guide Technology
ShopSabre CNC uses the latest in CNC Bearing Technology with 25MM Linear Guide Rails and Bearings on all Axis. Each axis has 4 Large Body Quad Bearing rollers with wipers to increase the performance of your machine. These Bearings assure the surfaces stay clean while increasing the machine rigidity under load which results in increased performance and reduced maintenance in large part due to the ball bearing technology.
10. Industrial Precision Gantry
Just like our Frames, our gantry construction is constructed of massive heavy wall 6x12 Tubes that have been FEA Designed and Tested to provide higher cutting forces and less vibration. The Bearing Spacing on our gantries are larger than competition’s machines to better handle the routing forces while increasing cut speeds.
11. Industrial Gantry Uprights
Like everything on a ShopSabre, the Gantry uprights are also more industrial. Using High
Quality North American Structural Steel these uprights increase the bridge clearance to 12” Standard and provide more rigidity for better cutting quality and versatility.
12. Bi - Directional Rotary ATC Option
ShopSabre Rotary Carousel ATC Option is the most advanced ATC Technology on the market. Unlike competitors’ systems this ATC Carousel is direct drive through planetary
gear connection with bi-directional tool changing which allows the tool changer to travel the shortest distance to the next tool regardless of direction. Also, this ATC system provides no belts or slides, it operates just like every ShopSabre system-simple, fast, and effective!
Details
- Highlighted Features
- Software & Controller
- Uses & Applications
- Materials Cut
- Options
- Relevant Education
- Downloads
Highlighted Features
- Mitsubishi M80 Dedicated Control Technology with Fiber Optic Communication and Dedicated CNC CPU – Watch our Mitsubishi M8 Series Video
- Italian HSD Electric Fan Cooled Spindle available in 1ph. or 3ph. operation with or without Auto Tool Changer (ATC) Option. (100% Duty Rated)
- Powered 100% by over-sized ball screw drive systems with a Dual Driven Y Axis (Long Axis) and our Anti-Whip Technology– Watch our ball screw video!
- Industry Leading Mitsubishi Components including Industrial Digital A/C closed loop brushless servo motors (1KW) with glass encoder technology and individual drive amplifiers with digital tuning – Watch our top servo motor technology video!
- Industrial Welded, stress-relieved, and Aerospace milled structural steel tube frame construction –
- Industrial structural steel tube gantry uprights and Steel Cross bridge with Milled Mating Surfaces– Watch our steel vs aluminum video!
- High Performance 25MM linear profile guide rails and bearings with Quad Rollers on all axis
- ShopSabre State-of-the-art Tool Measure Technology – Watch our tool measure video!
- ShopSabre Re-enforced Z Axis Technology with Tool Plate Stiffeners and Optional Super Z Technology!
- ShopSabre Advanced Dust Skirt Technology
- Vectric VCarve PRO CAD/CAM Full License Software
- ShopSabre Advanced Multi-Axis Mitsubishi M8 Series Dedicated High Speed High Accuracy Controller with ShopSabre User Interface and at machine Ease of Operation.
- Machine Operator Control Tower with full Networking and file management via USB and internet connectivity
- Free SabreNation Life-Time Tech Support via Phone, Email, and Remote Diagnostic! – Watch our support video!
- Free SabreNation Life-time Training and SabreNation University Access!
- Included Complete Warranty
- Quick and Effortless Installation – Machine Ships Fully Assembled with No Installation Assistance Required!
- MADE IN THE U.S.A. — American Manufactured & Engineered using FEA Software – Watch our engineering video!
- Grow with your business by expanding options that meet your exact needs – Watch our expansion equipment video
Software & Controller
- Vectric V-Carve Pro – Features nesting, 2D, 2.5D, 3D CAM capabilities, Vbit carving, sign making, photo importing, 4th axis capabilities, drill cycles, and much more! Watch Video Now
- Drawing to cut file in under 30 seconds
- Easy to learn with included training, tutorials, and support
- Just point and click! Pick cut strategies (Use a large bit to hog out the areas and a small bit to clean up the details)
Uses & Applications
The IS-M Series has unlimited uses and applications, including:
- Nested-based manufacturing
- Sign making
- Engineering
- R&D/Job shops
- Cabinet/Door/Closet manufacturing
- Live Edge
- Musical instrument manufacturing
- High production
- Solid Surface work
- Non-Ferrous material processing
- Aerospace
View All Applications
Materials Cut
The IS-M Series can accurately cut virtually any hard material including:
- Wood
- Acrylic
- Plastic
- Foam
- Aluminum
- Brass
- and More
Options
Standard Available options
Available attachments for ShopSabre CNC router models. Please note that some options may not be available on all models or with other options. Some options may result in limiting the cutting/working areas. Contact us for more details
- Manual Change HSD Spindles in 4HP or 9.3HP
- Auto Tool Changer Systems – 10 Positions with HSD Spindles in 5HP,10HP, or 13HP
- Phenolic Table Top
- Full Aluminum T-Slot Table Top
- Hybrid T-Slot/Vacuum Table Top (Available with Phenolic Upgrade)
- Hybrid T-Slot/MDF Table Top (Available with Phenolic Upgrade)
- Vacuum Table with 4 Zones and 8 Table Pipes
- FPZ Vacuum Pump
- Becker Vacuum Pump
- ShopSabre F4 Single Phase Vacuum Pump (Ask for Details/Limitations)
- Material Thickness Calibration Touch Pad
- Table Reference Pins (Pop-Up Pins) for Sheet Alignment – Availability dependent on Machine Model
- On-Table 4th Axis /Rotary Indexing Heads
- Braille/ADA Sign Attachments/Tooling
- Tangential Oscillating Knife System
- Dust Collector Options
- Wireless Hand Control Pendant with Jog Wheel
- Boring/Drill Head Attachments (Dependent on Machine Model & May Reduce Working Area)
- Multiple Cutting Head Attachments (2 or More Cutting Heads – May Reduce Working Area)
- Aggregate and C-Axis Attachments for Auto Tool Changer
- Nesting, Cabinet, 3D, 2D, and Photo Recognition Software Packages
- Safety Mats & Light Curtains
- Warning Light Bar
- Private 1 on 1 Training (On-Site and In House)
- 3D Laser Scanner Attachment for Quick 3D Copying (Ask for Details/Availability)
- Vacuum Pods
- Dust Dock ATC Containment Dust Skirt with Dock
- Dust Dock Manual Change Containment Dust Skirt
- Vortex Tooling Packages
- Mist System for Aluminum Cutting
- Air Blower for Plastic Cutting
- UL/CUL by Request
See all Accessories and Options
